Product Introduction
220V transparent universal relay, intermediate relay factory manufactured starter, large power relay, with various external structures, grounding type high-power relay, QIANJI high-power relay has various styles and specifications. There must be one that suits your choice.
Product Parameter (Specification)
|
Contact Ratings |
||
|
Contact Ratings |
2Z, 2H, 2D |
4Z, 4H, 4D |
|
Contact Resistance |
50MΩ (1A 6VDC) |
|
|
Contact Material |
Silver Alloy |
|
|
Contact Capacity |
10A/30VDC 250VAC |
3A/30VDC 250VAC |
|
Specification |
||
|
Insulation Resistance |
500MΩ, 500VDC |
|
|
Dieletric Strength |
BCC 1500V 1 min |
|
|
BOC 1000V 1 min |
||
|
COC 1500V 1 min |
||
|
Operate Time |
25ms/25ms |
|
|
Terminal Type |
PCB, Socket |
|
|
Coil Ratings |
||
|
Norminal Coil Power |
0.9W/1.2VA |
|
Product Feature And Application
Excellent Performance
√ Contact gold plated type
√ Switching between two groups
√ Stable action time
√ PCB socket
Production Details
|
Coil Versions |
|||||||
|
Nominal Voltage VDC |
Pull-in Voltage VDC |
Release Voltage VDC |
Coil Resistance Ω: ±10% |
Nominal Voltage VAC |
Pull-in Voltage VAC |
Release Voltage VAC |
Coil Resistance Ω: ±10% |
|
5 |
4.8 |
0.50 |
30 |
6 |
4.8 |
1.80 |
12 |
|
6 |
4.8 |
0.60 |
40 |
12 |
9.6 |
3.60 |
42 |
|
12 |
9.6 |
1.20 |
160 |
24 |
19.2 |
7.20 |
168 |
|
24 |
19.2 |
2.40 |
640 |
48 |
38.4 |
14.4 |
675 |
|
48 |
38.4 |
4.80 |
2560 |
110 |
96.0 |
36.0 |
3500 |
|
110 |
88.0 |
11.0 |
12100 |
220/240 |
176.0 |
66.0 |
14000/16500 |
Product Qualification
During the production process, we use fully automated production lines and will conduct manual testing to ensure high quality standards. Most importantly, kilobase relays have the advantage of providing you with satisfactory products. Not only in terms of product quality and style, but also in terms of service. When you decide to collaborate with Qianji, it means that your business will grow significantly in the coming year. If you have any needs for our products, you can contact us by email.
FAQ
1. Who are we?
QIANJI was established in 2000, specializing in the production of relays and enjoying a good reputation in China and overseas. Continuously growing and becoming an excellent factory in the same industry.
2. Why did you choose us?
- OEM/ODM accepted.
- I have been professionally engaged in this field for 20 years.
- We can accept small orders or sample orders.
- Directly supplied by the factory, with low prices and guaranteed quality.
- Professional after-sales service.
3. Our payment and logistics?
Payment method: telegraphic transfer/Western Union transfer/letter of credit PayPal.
Transportation conditions: DHL, UPS, FEDEX, TNT, EMS.
The sample order is delivered within 24 hours, and the order delivery cycle is within 3 days.
Available samples: Yes.
FOB Port: Guangzhou. Ningbo
4. What can you get from us?
1) Excellent products (unique design, strict quality control).
2) Considerate service (OEM, ODM, after-sales service, fast delivery).
3) Professional business consulting.
5. Payment method?
PayPal, T/T, Western Union remittance, express remittance, or other methods.
